LVS-9510 Barcode Verifier – ISO/IEC & GS1 Grading

The LVS-9510 is for off-line verification of bar codes to ISO/IEC standards. The LVS-9510 is unique in the world of ISO verification due to its ease of use and ability to verify linear and two-dimensional (2D) codes without any change of equipment; autodiscriminate the symbology, narrow bar width and aperature to be used to evaluate the code; and highlight trouble spots in the code. Additional outstanding features include:

Omron Microscan · Barcode quality assurance

LVS-9510 · ISO/IEC · GS1

LVS-9510 barcode verifier – barcode quality grading to ISO and GS1 standards

The Omron Microscan LVS-9510 is a desktop barcode verifier that grades the print quality of 1D and 2D barcodes to ISO/IEC standards. Place the label on the glass, and the verifier identifies the code, gives it a quality grade and uses colour coding to show what is wrong. You catch faulty labels before they reach your customers.

Omron Microscan LVS-9510 barcode verifier
5 MPcamera
1D + 2Don one device
GS1 UScertified (UDI)
21 CFR 11ready
A–F

A quality grade for every barcode

Retail chains, pharmacies and logistics partners require barcodes that meet GS1 and ISO quality requirements. The LVS-9510 gives each code an ISO quality grade and a report you can save for audits. You avoid unreadable codes, returns and complaints before the goods ship.

Barcode scanner or barcode verifier?

Barcode scannerOnly tells you whether the code can be read. A good scanner reads even a poor code, so it can’t tell you whether the code will work on other people’s scanners.
Barcode verifierMeasures code quality in a standardised way: contrast, edges, quiet zones, defects and decodability. The result is a grade that matches your customers’ requirements.

Features

1D and 2D on one device

Linear, stacked and 2D codes such as EAN, GS1-128, Data Matrix and QR, including several codes on the same label.

Automatic detection

The verifier detects the symbology and selects the correct measuring aperture automatically. No manual adjustment needed.

Colour-coded analysis

The problem area is highlighted in colour, so you see straight away whether the fault comes from the printer, the label or the layout.

GS1 data validation

The EAIV add-on checks the content of GS1 Application Identifiers, and the Multi-Sector add-on analyses several codes at once.

Audit-ready reports

Saveable quality reports, user management and 21 CFR Part 11 readiness for the pharmaceutical and healthcare sectors.

Calibrated out of the box

Comes with a NIST-traceable calibration card for verifying measurement accuracy.

Applications

  • Label printers and packaging plants
  • Food and retail suppliers
  • Pharma and healthcare (UDI)
  • Logistics and GS1-128 pallet labels
  • Production quality assurance
  • Printer commissioning and maintenance

Models and technical specifications

ModelField of viewCalibration card
9510-5-1.7544 mmEAN/UPC
9510-5-3.076 mmEAN/UPC
9510-5-4.0102 mmEAN/UPC
9510-5-4.5114 mmEAN/UPC
9510-5-6.250159 mmGS1-128
FeatureOmron Microscan LVS-9510
Camera5.0 MP monochrome camera
IlluminationWhite LED, 660 nm red filter
Glass size127 × 178 mm
StandardsISO/IEC 15415, 15416, 15418, 15426-1, 15426-2; ISO/IEC TR 29158 (DPM); GS1; ANSI; UDI, HIBC, AIAG, MIL-STD-130
1D codesIncluding EAN/UPC, GS1-128, Code 128, Code 39, ITF-14, GS1 DataBar, Codabar, Pharmacode, PZN
2D codesIncluding Data Matrix (also GS1), QR, Micro QR, PDF417, MicroPDF417, Aztec, MaxiCode, composite codes
InterfaceUSB 2.0; runs on a Windows PC with LVS95XX software
Power12 VDC, 2.5 A
Dimensions and weight267 × 282 × 230 mm (H × W × D); 2.72 kg
Operating environment+10…+30 °C; humidity 20–80 %, non-condensing
Software15 languages, user management (incl. Active Directory); Multi-Sector, EAIV and Automatic Login add-ons
<
